NGP-series Liquid Metering Pumps


Product Name

Part #

Price

Twin Piston 68.4 GPM NGP-9055 $5,103.00
Twin Piston 42.0 GPM NGP-8055 $4,587.00
Single Piston 34.2 GPM NGP-7055 $3,323.00
Single Piston 21.0 GPM NGP-6055 $2,786.00
Contact to order


Please reference part # NGP-6055 when
you get in touch. Thank you!

More Information

Permits you to set the desired rate and apply accurately regardless of variations in ground speed.

Features
1. New Single Valve Cap
- One piece valve cap allows for easy check valve access without removing the hoses. Easy to service in the field.
2. New Outboard Cylinder - Plunger packing can be inspected or replaced in the field without removing the hoses.
3. New Main Shaft Seals - The newly designed main shaft seals incorporate a dual wiper that is enclosed in a grease cavity to flush out contamination, resulting in
a longer life.
4. New Check Valve Design - A positive check o-ring seal offers enhanced priming and is more forgiving in handling debris, which ensures accuracy.
5. Universal Piston Rod Seals - Three Stage Dynamic Design - Primary wet end "V" packing, primary crankcase "V" packing and secondary crankcase o-ring seals work in unison to offer multiple stage protection between the wet end and crankcase. This reduces pump weepage while maximizing pump life.
6. Standard Main Shafts - Standard single and double piston pump crankshafts are universal in the NGP line for modular upgrades such as clutches and ON-THE-GO variable rate. (Modules to be released soon.)

Choose the right pump for your application:



Part #



Description

Cap.

US gpm



Inlet



Outlet

Max Speed

Max

Psi

NGP-9055

Twin Piston

68.4

1-1/2"

1-1/2"

450

120

NGP-8055

Twin Piston

42.0

1-1/2"

1-1/2"

450

120

NGP-7055

Single Piston

34.2

1-1/2"

1-1/2"

450

120

NGP-6055

Single Piston

21.0

1-1/2"

1-1/2"

450

120
