John Blue Wet Seal Transfer Pumps w/Electric Motors


Product Name

Part #

Price

2-inch Straight; 5 hp 3-phase S3220-E5D3 $1,596.00
2-inch Straight; 5 hp single-phase S3220-E5D1 $2,009.00
3-inch Straight; 10 hp 1-phase TEFC S-3320-E10T-1 $4,764.00
3-inch Straight; 10 hp 3-phase TEFC S3320-E10T $2,521.00
3-inch Straight; 15 hp 3-phase TEFC S3320-E15T $2,866.00
2-inch Self-Priming; 5 hp drip-proof 3-phase* SP3240-E5D3B $1,727.00
2-inch Self-Priming; 5 hp drip-proof 1-phase* SP3240-E5D1B $1,992.00
3-inch Self-Priming; 10 hp 3-phase TEFC* SP-3340-E10TB $3,034.00
3-inch Self-Priming; 10 hp 1-phase TEFC* SP-3340-E10TB-1 $4,221.00
3-inch Self-Priming; 15 hp 3-phase TEFC; HiFlow SP-3350-E15TB $3,446.00
Contact to order


Please reference part # SP-3350-E15TB when
you get in touch. Thank you!

More Information

Description

Cap.

GPM

Max

PSI

Max

RPM

Recommended

Min HP

2" Straight Pumps

197

39

3500

5

3" Straight Pumps

365

60

3500

10

2" Self-Priming Pumps

152

42

3500

5

3" Self-Priming Pumps

308

65

3500

10









  • May be operated DRY without damaging the sealsDouble, wetted seals are continuously lubricated to reduce wear.
  • Patented Vac-U-Seal design eliminates pressure on the seal by
  • creating a vacuum around the seal.
  • Heavy cast iron construction for extended service life.
  • Closed impeller design minimizes thrust loading on the drive motor,
  • extending its service life.
  • HINT: Both Straight and Self-Priming pumps incorporate the double wetted
  • seals. Straight pumps, which have a greater capacity, should be used only in applications where the pump is sure to be fully charged with head pressure. Otherwise, use a self-priming pump.
